The heart of the Smartive system
Mini Server
The Smartive Mini Server is a DIN-rail-mountable, 5 VDC-powered building automation mini server and I/O controller. It comes with Linux-based control, Wi-Fi/BLE connectivity, 33 3.3 V digital inputs, a 1-Wire sensor interface, an extender port and 6 dry-contact relay outputs.
Specifications
- 33 digital inputs (0-3.3 V)
- 6 dry-contact relay outputs, max. 5 A/channel
- Built-in temperature and humidity sensor
- Extender port for connecting 8 more modules
- Switched circuit: max. 40 V SELV/PELV
- 5 VDC power from a CE-marked SELV/LPS or PS2 power supply
- Linux-based control with Wi-Fi/BLE connectivity
- DIN-rail mountable, 137.6 x 93 x 32 mm
Local Smartive firmware
1-Wire sensor interface
Extender port for Smartive modules
OTA updates with digital signature
Downloadable documents
CE/RoHS documentation, declarations and installation labels.
